SPECIFICATIONS
Brand Name: UNI-T
Origin: Mainland China
Theory: Thermometer Hygrometer
Max Measuring Temperature: 120°C & Above
Display Type: DIGITAL
Certification: CE
Certification: FCC
Certification: RoHS
Certification: KC
Style: Handheld
Usage: Industrial
Model Number: UT306S UT306C
Power Type: AAA battery
Display Size: 1.9 Inches & Under
Is Smart Device: YES
UNI-T UT306S UT306C: Non Contact Digital Thermometer
Household/ Industrial: Infrared Laser Temperature Tester Meter Gun
Temperature range: 50 ℃ - 500 ℃ (- 58 ℉ - 932 ℉)
Data retention function: Trigger locking function
Sound alarm function: Low battery prompt function
Choice: yes
UNI-T UT306S UT306C Infrared Thermometer
The UT306S UT306C is robust and easy to use. Users can measure the surface temperature without contacting the object. This product series can be used in various fields such as food industry, machine maintenance, metal working, cold storage, and other industrial fields.
Features
Wide Temperature range: -50℃~500℃
Lock the temperature without pulling the trigger
High and low temperature alarm
℃/℉ options
Auto power off
Low battery indication
Parameter
Specifications | ||
Model |
UT306S |
UT306C |
Temperature range |
-50℃~500℃ |
-50℃~500℃ |
Laser type |
Single |
Circle |
Accuracy |
±2°C or ±2% |
±2°C or ±2% |
Resolution |
0.1°C |
0.1°C |
Distance to spot ratio |
12:01 |
12:01 |
Response time |
≤250ms |
|
Emissivity |
0.10~1.00 adjustable |
|
Laser class |
Class 2 |
|
Laser power |
<1mW |
|
Laser wavelength |
630nm~670nm |
|
Spectral response |
8μm~14μm |
|
Features | ||
Display type |
TN-LCD |
EBTN-LCD |
Unit selection |
°C/°F |
|
Laser on/off |
√ |
|
Data hold |
√ |
|
Auto power off |
√ |
|
Low battery indication |
√ |
|
MAX/MIN/AVG/DIF mode |
√ |
|
High/low temperature alarm (audible) |
√ |
|
Drop test |
1m |
|
General Characteristics | ||
Power |
1.5V AAA x 2(No include) |
|
Product color |
Red and grey |
|
Product net weight |
161.5g |
Wide measurement range
Temperature range:-50℃~500℃(-58~932°F)
Lock measurement
UT306S can lock the temperature without pulling the trigger.
Circle Laser(UT306C)
Fast response
Response time ≤250ms
Emissivity Adjustable
0.10~1.00 adjustable
LCD backlight display
Notice please: battery no include!
